8555-M512-O1 Rev D 01/15 8
KEYPAD FUNCTIONS
DO NOT operate the keypad with pointed objects (pencils, pens, etc).
Damage to keypad resulting from this practice is NOT covered under warranty.
Figure No. 7
This is the ON/OFF key. With the MV1 off, pressing this key will apply power
to it and turn on the display. If the MV1 is already on, pressing the key will turn
it off.
Basic Functions
This is the ZERO key. It is used to reset the display to zero up to the selected
limit of either 4% or 100% of the scale capacity. The zero limit is set during
setup and calibration of the MV1.
This is the UNITS key. This key is used to change the weighing units to the
alternate units of measurement. For example, with pounds displayed, pressing
this key will change the weighting units to kilograms. NOTE: This feature
must be enabled during setup and calibration for this key to be operational.
