ECG100+ - ECG200+ - ECG100S - ECG200S
5. INTRODUCTION
5. INTRODUCTION
5.1. Purpose of the manual
This manual deals with the ECG100+/ECG200+/ECG100S/ECG200S devices.
The manual represents a guide for the execution of the following operations:
Reasonable use of the electrocardiograph, of the function keys and of the sequence of menus.
Preparation of the device for use. (Section 6)
Acquisition, printing and storage of ECG tracing. (Section 7)
System settings. (Section 8)
Connectivity and transmission of ECG tracings. (Section 10)
Device upgrading (Section 11)
Troubleshooting and electrocardiograph maintenance. (Section 12)
5.2. Recipients
This manual is intended for professional healthcare operators. They are therefore presumed to have specific
knowledge of medical procedures and terminology, as required by clinical practice.
5.3. Intended use
ECG100+/ECG200+/ECG100S/ECG200S is a high-performance, multi-channel, interpretative resting
electrocardiograph.
The ECG signal is acquired with a 10-wires patient cable and is displayed in real time on a LCD screen
integrated in the device. The electrocardiograph can analyse and store the ECG traces, send them to an
external peripheral via Internet or via USB, print the 12 lead ECG in automatic or manual mode by means of
a thermal printer.
The device is intended for assessment and diagnosis of cardiac functions. In any case the results of analysis
performed by the electrocardiograph must be validated by a Physician.
The device is intended for use in hospitals, in medical clinics and doctor’s offices of any size.
The device is indicated for use to acquire, analyse, display and print electrocardiograms.
The device is intended to provide the physician with an automatic interpretation of the ECG to be
reviewed by a physician.
The device is indicated for use in a clinical setting, by a physician or by trained personnel who are
acting on the orders of a licensed physician. It is not intended as a sole means of diagnosis.
