4.5 DISASSEMBLING THE SCOOTER
1. Lift the tiller to stand the scooter in an upright position (Fig. 4.1)
2. Push the front frame and then pull out the connecting pin (Fig. 4.2)
3. Lean the front frame forward to 45 degree (Fig. 4.3)
4. Pull to separate the front frame from the rear frame (Fig. 4.4)
ļ Warning
Always unplug the rear section electrical connector before separating the two sections.
Fig. 4.1 Fig. 4.2
Fig. 4.3 Fig. 4.4
