CareCo ECLIPSE - Specifications

23
9 . S P E CI F I C AT IO N
Model
CareCo Eclipse
Dimension (L x W x H mm)
(L x W x H ins)
940mm x 490mm x 900mm
37” x 19” x 35.5”
Base weight (without battery)
57.2lb / 26kg
Battery weight
22lb / 10kg
Seat weight
16.5lb / 7.5kg
Total weight
95lbs / 43.5kg
Battery
12AH x 2
Charger
2A
Charging time - hours
>6h
Front Wheel
8" x 2” / 200mm x 50mm
Rear Wheel
8" x 2” / 200mm x 50mm
Anti-tip Wheel
2" / 50mm
Driving System
Direct rear wheels (with differential gear)
Top Speed
4 mph / 6.4 kph
Turning radius
35.4” / 900mm
Climbing angle
6 - 8°
Cruising range
6 – 7.5 miles / 10 – 12 km
Max. User weight
250 lbs / 113kg
The manufacturer reserves the right to modify the specification if necessary. The final
specification is subject to the individual scooter you purchase from CareCo.
Note:
Maximum driving distance is based on an ambient temperature of 20C, a 75kg driver and
brand new fully charged batteries; with a constant driving speed of 4 mph on a flat surface.
