Carel easy way aria User Manual

26
GB
easy way ARIA +030220841 - rel. 1.0 - 26.10.2007
Cooling mode
In ou mode the cooling request sees the following trend.
RH = 0•
RC•
Fig. 4.d.o
Heating mode
In mode the heating request sees the following trend.
RC = 0•
RH•
Fig. 4.d.p
Automatic humidi cation/dehumidi cation algorithm
The humidi cation/dehumidi cation algorithm is used to inform the
master-supervisor of the humidi cation or dehumidi cation request in
the location where the terminal is installed.
If the humidity sensor is  tted (see par. 6.1.2) the terminal will be able to
activate the automatic humidi cation/dehumidi cation according to the
set point and the value read by the humidity sensor.
Automatic mode
In mode the heating/cooling request sees the following trend.
Fig. 4.d.q
Fan mode
In the algorithm is disabled:
RC = 0•
RH = 0•
The function is disabled if Di = 0% RH•
The humid. request (RU) is enabled in •
, ou
The dehumid. request (RD) is enabled in • ou
symbol description min max def um type index R/W notes
Umid Ambient humidity 1.0 100.0 --- %rH A 2 R
-
Set umid Humidity set point 0.0 100.0 50.0 %rH A 7 R/W
-
Di
Humidi cation algorithm di erential
0 algorithm disabled
0.0 25.0 5.0 %rH A 13 W
-
RU
Humidi cation request
0 request not active
1 request active
01- -D 9R
-
RD
Deumidi cation request
0 request not active
1 request active
0 1 - - D 10 R
-
Tab. 4.q
Requests in cool, heat, auto mode
Fig. 4.d.r
Dry mode
In mode the dehumidi cation request is always active (manual
dehumidi cation), irrespective of the set point and humidity reading.
RD = 1•
RU = 0•
Fan mode
In mode the algorithm is disabled:
RD = 0•
RU = 0•
Display
If humidi cation request RU = 1, the terminal will display the symbol
If dehumidif. request RD = 1, the terminal will display the symbol .
Fig. 4.d.s Fig. 4.d.t
