4.3 Functions
Display
The numeric  elds on the display (1 and 2 in Fig. 4.b) can be con gured
based on requirements.
Parameters loc1 and loc2 are used to customise these  elds.
Fig. 4.d.a
Main display (loc1)
Fig. 4.d.b
loc1 display notes
1 Temperature Default
2 Set Temperature COMFORT displayed if COMFORT function active (loc)
3 Humidity “---” if humid. sensor not  tted
4 Set Humidity -
Tab. 4.h
Secondary display (loc2)
Fig. 4.d.c
loc2 display notes
0 no display Blank
1 Temperature -
2 Set Temperature COMFORT displayed if COMFORT function active (loc)
3 Humidity “---” if humid. sensor not  tted
4 Set Humidity -
5 Clock Default
Tab. 4.i
par. description min max def UOM type index R/W notes
loc 1 Field shown on main display 1 4 2 - I 19 R/W
-
loc 2 Field shown on secondary display 0 5 5 - I 20 R/W
-
Tab. 4.j
