Carel mastercella Technical Leaflet

+050004104 rel. 2.2 del 26.09.07
17
9. EXEMPLU DE CONEXIUNI TERMINALE/EXAMPLES OF TERMINAL
BOARDS CONNECTION/EXEMPLE DE CÂBLAGE DE LA CARTE DE CONNE-
XION/ANSCHLUSSBEISPIEL FUER DIE STECKVERBINDUNGEN/EJEMPLOS
DE CONEXIÓN TARJETAS BORNES/EXEMPLO DI LIGAÇÃO DA PLACA DE
CONECTORES
Fig. 8.a

Carel mastercella Specifications

General

Series	Mastercella
Front Protection	IP65
Protection Rating	IP65 (front)
Control Type	PID, ON/OFF
Display	LCD
Inputs	NTC, PT1000
Outputs	Relay, SSR
Storage Temperature	-30°C to +70°C
Analogue Outputs	4-20 mA, 0-10 V
Serial Communication	RS485, Modbus RTU
Relative Humidity	<90% RH non-condensing
