Introduction
• Easy use, installation and maintenance
• Universal valve body for the entire range, suitable for any size
Notice: the unipolar electronic valve must be sized according to the type of refrigerant used, the operating point and the
maximum operating pressure differential (MOPD). For correct sizing, see the official CPQ tool (https://cpq.carel.com).
The following specifications must therefore be complied with if using a unipolar valve with MPXone Advanced:
1. For HFC/HFO refrigerants:
Maximum size E3V45 with MOPD = 35 bars (507 PSI) (1).
Part number Description
E2BR00SF1(0/1)(*) Valve body E2VZ 12-12 ODF
E2VATT**Z(0/1)(*) Actuator with integrated valve port
E2VSTA032(0/1)(*) Unipolar valve stator, 2 m cable, JST connector
E2VSTA033(0/1)(*) Unipolar valve stator, 0.3 m cable, superseal connector
(0/1)(*): single/multiple pack (20 pcs.)
2. For CO2 refrigerant (R744):
E2V-Z: maximum size E2V30 with
• MOPD<35 bars (507 PSI)
• PS≤80 bars (1160 PSI) [CE]
• PS≤45 bars (652 PSI) [UL].
Part number Description
E2BR00SF1(0/1)(*) Valve body E2VZ 12-12 ODF
E2VATT**Z(0/1)(*) Actuator with integrated valve port
E2VSTA032(0/1)(*) Unipolar valve stator, 2 m cable, JST connector
E2VSTA033(0/1)(*) Unipolar valve stator, 0.3 m cable, superseal connector
(0/1)(*): single/multiple pack (20 pcs.)
E2V-C: maximum size E2V24 with
• MOPD
– E2V03-EV209 <120 bars (1740 PSI)
– E2V11-E2V18 < 110 bars (1595 PSI)
• PS
– E2V**CS0**, E2V**CS1**, E2V**CWA**: 140 bars (2030 PSI)
– E2V**CSF**: 90 bars (1305 PSI)
E2V-ZC
• MOPD
– E2V03-E2V09: 120 bars (1740 PSI) [CE]
– E2V11-E2V18: 110 bars (1595 PSI) [CE]
– E2V24: 60 bars (870 PSI) [CE]
• PS
– 140 bars (2031 PSIg) [CE]
Part number Description
E2V**CWAC(0/1)(*) Electronic expansion valve 3/8”-3/8” ODF
E2VSTA032(0/1)(*) Unipolar valve stator, 2 m cable, JST connector
E2VSTA033(0/1)(*) Unipolar valve stator, 0.3 m cable, superseal connector
(0/1)(*): single/multiple pack (20 pcs.)
3. Maximum valve cable lengths:
< 2 m with unshielded cable, 9m with AWG24 shielded cable.
Part number Description
E2VCABS3U0 Valve extension cable, 3 m - IP67 superseal connector
E2VCABS6U0 Valve extension cable, 6m - IP67 superseal connector
Notice: configurations with longer distances must be validated by the customer and are not guaranteed in advance by
CAREL.
1. Except for the E2V35 valve with R410, whose maximum limit is defined by: MOPD=26 bars.
2. CS0, CS1 and CW models up to 140 bars (2030 PSI), CSF and CZ models up to 90 bars (1305 PSI).
1.2.9 USB/RS485 converter (CVSTDUMOR0)
Electronic device used to interface an RS485 network to a personal computer via the
USB port. See technical leaflet +050000590.
CVSTDUMOR0
Fig. 1.i
