Carel MPXone - Page 17

17
ENG
mpxone +0300086EN rel. 2.2 - 13.11.2023
Installation
2.6.2 DIN rail Advanced model
300086_048_R01
L
N
J1
NL
115-230 VAC 50/60 Hz
J5 J4
J3
J2
J7 J6
J1
J5 J4
J3
J2
J7 J6
J1
Secondary 1
Supervisor/BMS
EXV valve
Secondary 2
...up to 9 secondary
Remote display
shield
Fig. 2.o
300086_049_R01
G
G0
VBAT
nero/black
bianco/white
verde/green
backup module
Fig. 2.p
