Carel pCO compact PCOX000AA0 - Analogue Inputs

8
“pCO compact” +050003343 - 1.3 - 12.09.2016
ENG
2.6 tLAN network connection
Type Asynchronous half duplex 0/5 Vdc, non-dierential
Transmission speed 9.6 Kbps or 19.2 Kbps selected via software
Maximum number of units connectable Maximum 5 units allowed
Connector for tLAN network 2-pin plug-in connector, pitch 3.81 mm (J7)
Tab. 2.d
Note:
• The tLAN serial (J7) can be used as an alternative to either the FieldBus serial available on the 3-pin connector p. 5.08 (J8); or
to the PLD terminal connection available on the special 4-pin connector (J6).
2.7 Analogue inputs
Maximum lenght cable 10 m
Analogue conversion A/D converter, 10-bit CPU built-in
Models TYPE A TYPE B
CAREL NTC -50T90 °C; R/T 10 kΩ at 25 °C or HT NTC 0T150 °C B1, B2, B3, B4, B5, B6, B7, B8 B1, B2, B3, B4, B5, B6
Voltage, 0 to 1 Vdc B1, B2, B3, B4, B5, B6
B1, B2, B5, B6
B1, B2, B5, B6
B1, B2
B3, B4
Voltage, 0 to 5 Vdc ratiometric
Voltage, 0 to 10 Vdc
Current, 0 to 20 mA or 4 to 20 mA
PT1000 -100T200 °C; R/T 1000 Ω at 0 °C
Voltage-free digital input (5 mA) B5, B6, B7, B8 B5, B6
Total 8 6
Tab. 2.e
Warning: for the power supply to any active probes, the +21 V available on the VDC terminal can be used, maximum current
available Imax= 60 mA, protected against short-circuits. For the power supply to the 0 to 5 Vdc ratiometric probes, use the +5
VREF, maximum current available Imax= 60 mA, protected against short-circuits.
Specications
Time constant 0.5 s
Precision ± 0.3 % of full scale
Classification of measuring circuits Category 1 (IEC EN 61010-1)
Tab. 2.f
Warning: separate as much as possible the probe and digital input signal cables from the cables carrying inductive loads and
power cables to avoid possible electromagnetic disturbance.
