Carel pCO compact PCOX000AA0 - DC Power Supply

15
“pCO compact” +050003343 - 1.3 - 12.09.2016
ENG
DC power supply
J 7
J10J 9J 8J 5
J 1
G G0 +5Vref +VDC ID1 GND
J 3
C1 NC1 NO1
J 2
SYNC
B1 B2 B3 GND
serial card 1
J 4
J 6
TLAN
GND
C2
NO2
GND
Y2 Y1
GNX
ISOLAT E D
Tx/Rx
PWM 0/10V
GNDTx/Rx
J12
GND
ID2
B7 B8
J11
NO4 NO5 NO6 NO7
C3
NO3
C3
24 V (+10/-15%); 50/60 Hz
48 V (36Vmin…72 Vmax)
input voltage: max. power:
14 VA /11 W
48Vdc
800mA T
50mA T (5 x 20)
24Vac
(*)
Fig. 4.c
(5 x 20)
Fig. 4.c
SEPARATE power supply for controller & SYNC
(*) the use of tLAN port excluded the use of Field Bus port and vice versa.
