7.1 Power / Probe Overload Cuto
The Apollo CW4000 system is classified by the U.S. Code of
Federal Regulations as a Class I device. In Europe the Apollo
system is classified as a Class IIa device. In Canada it is Class II.
Power is provided to the Apollo CW4000 system via a Hospital
Grade external power supply included with the purchased system:
• External, Universal AC input (100-240 vac 47-63 hz),
100 watts, DC-out: 12 V, 8.33 A.
• For U.S. applications, the AC mains plug is
Hospital Grade, NEMA 5-15P-HG
• Contact Care Wise or your Care Wise distributor to
supply or replace the proper AC mains plug/cable for
your application or governmental/country requirements.
• The guidelines set forth by your recognized National
Certification Body (NCB) may require additional
certification. If required, contact Care Wise or your
Care Wise distributor for assistance.
CAUTION: Use only a power supply provided by Care Wise
specifically for the C-Trak
®
Apollo System to prevent the
occurrence of shock, fire or product damage.
Bias voltage supplied to the probe is generated by a stable, high
voltage supply embedded within the C-Trak
®
Apollo system.
The voltage is set at 900 vdc and the current is always less than
10 µA. Any current exceeding this threshold will immediately turn
OFF this voltage. The system can only be turned back ON via
direct user interaction as directed by the displayed error message.
Unauthorized attempts to repair the probe, cable or the C-Trak
®
Apollo computer system can result in a minor electrical shock.
Neither the external power supply nor the power supply
inside the computer are serviceable by the user.
CAUTION: Use only the hospital grade power supply and
power cord provided by Care Wise. The use of any other
power supply or power cord may cause harm to the
user, damage the equipment and void the warranty.
Contact Care Wise for repair or replacement parts.
Automatic shuto is a safety feature of the C-Trak
®
Apollo
system. Ten micro amperes (10 µA) is the international standard
for the maximum allowable leakage current from a medical
device operating o of an external power source that contacts a
patient’s body during use. If current greater than 10 µA were to
flow to the probe, the C-Trak
®
Apollo system would immediately
shut o all current to the probe to prevent any risk to patient
or surgeon. A warning dialog would then appear on screen
instructing the user how to proceed safely.
7.2 LCD Display
The 17" LCD Resistive Touch display is integral to the C-Trak
®
Apollo CW4000 System. The screen is sensitive to finger pressure
and does not require a stylus. Resolution is 1280 x 1024.
7.3 Probe Connector
Series ‘MHV’ coaxial connector for ALL probes
[CAUTION: This is NOT a “BNC” style connector.]
7.4 Size
420 mm (W) x 360 mm (H) x 80 mm (D)
7.5 Weight
Approximately 7 kg (15.4 lbs).
7.6 Finish
Anti-bacterial coated plastic.
7.7 Mode of Operation
Continuous operation.
7.8 Serial Numbers
The serial number of the analyzer is located on the back of the
unit on the Product Label. The serial number for the probe is
engraved on the side of the probe at the base of the probe
body, near the cable connection.
7.9 Environmental Limits
Operational Temperature 10-40˚ C (50˚ F to 104˚ F)
Storage Temperature 10-40˚ C (50˚ F to 104˚ F)
Operation Relative Humidity 30% - 75%, non-condensing
Storage Relative Humidity 30% - 75%, non-condensing
Atmospheric Pressure 700 hPa to 1060 hPa
Operational Altitude less than 2000 meters
(~6000 ft)
7.10 Label Legibility
In normal use, the operator of the CW4000 views the product
from the front, facing the computer screen usually at a distance
no greater than nine (9) feet. The ID/Serial Number Label is on
the rear of the product and is intended to be viewed in a normal,
room lighting environment (500 lux or greater) by a person with
a visual acuity (corrected, if necessary) of 20/20 at a distance
of approximately 12-18 inches (a normal reading distance).
Aside from the serial number, the information included on
this label is also available in the printed User’s Guide
(included with each product).
30
|
www.carewise.com
C-Trak Apollo
7.0 Technical Specifications
