Carimali DIVA COF - Machine Keypad; DIVA COF 2 GR Keypad Layout

LB.05099.02 Pag. 6 18/10/16
NOTE: The registration and technical data plate of the machine is on the right side of the electrical box under the drip tray.
MACHINE KEYPAD
 Machine keypads DIVA COF 2GR
Gr. 1 keypad
Gr. 2 keypad
11
12
13
14
15
21
22
23
24
25
Key 11
1 Ristretto key
Key 21
1 Ristretto key
Key 12
2 Ristretto key
Key 22
2 Ristretto key
Key 13
1 Continuous key
Key 23
1 Continuous key
Key 14
1 Espresso key
Key 24
1 Espresso key
Key 15
2 Espresso key
Key 25
2 Espresso key
