CARLO GAVAZZI VariFlex3 RVLF Series - Page 31

Group 11 Performance control functions
No. Description Range
Factory
setting
Unit Note
11-00 Reverse operation control
0: Reverse command is enabled
1: Reverse command is disabled
0 -
11-01 Carrier frequency (kHz) 1~16 5 KHz
11-02 Carrier mode selection
0: Mode 0, 3 phase PWM
modulation
1: Mode 1, 2 phase PWM
modulation
2: Mode 2, 2 phase random
PWM modulation
0 -
11-03
Carrier frequency reduction
by temperature rise
0: Disabled
1: Enabled
0
-
11-04 S-Curve acc 1 0.0~4.0 0.00 sec
11-05 S-Curve acc 2 0.0~4.0 0.00 sec
11-06 S-Curve dec 3 0.0~4.0 0.00 sec
11-07 S-Curve dec 4 0.0~4.0 0.00 sec
11-08 Skip frequency 1 0.00~650.00 0.00 Hz *1
11-09 Skip frequency 2 0.00~650.00 0.00 Hz *1
11-10 Skip frequency 3 0.00~650.00 0.00 Hz *1
11-11 Skip frequency bandwidth (±) 0.00~30.00 0.00 Hz *1
Group 12 Digital Display & Monitor functions
No. Description Range
Factory
setting
Unit Note
12-00 Extended display mode
00000~77777.
Each digit can be set to 0 to 7
00000 - *1
0: Default display
(frequency&parameters)
1: Output current
2: Output voltage
3: DC voltage
4: Temperature
5: PID feedback
6: Analog signal input. (AVI)
7: Analog signal input. (ACI)
12-01 PID feedback display format
0: Integer (xxx)
0 - *11: One decimal place (xx.x)
2: Two decimal places (x.xx)
12-02 PID feedback display unit setting
0: xxx--
0 - *11: xxxpb (pressure)
2: xxx (ow)
12-03 Custom units (line speed) value 0~65535 1500/1800 RPM *1
12-04
Custom units (line speed)
display mode
0: Drive output frequency is
displayed
0 - *1
1: Line speed. Integer. (xxxxx)
2:Line Speed.
One Decimal place (xxxx.x)
3: Line speed.
Two decimal places (xxx.xx)
4: Line speed.
Three decimal places (xx.xxx)
Specications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network.18/11/2014 29
Motor Controllers AC Variable Frequency Drives Type Variex
3
RVLF
