CARLO GAVAZZI VariFlex3 RVLF Series Quick Start Guide

28 Specications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network. 18/11/2014
Motor Controllers AC Variable Frequency Drives Type Variex
3
RVLF
Group 10 PID function Setup
No. Description Range
Factory
setting
Unit Note
10-00
PID target value selection (when 00-
05\00-06=6 ,this function is enabled)
0: Potentiometer on keypad
1: Analog signal input. (AVI)
2: Analog signal input. (ACI)
3: Frequency set by communication
4: KeyPad frequency parameter -02
1 - *1
10-01 PID feedback value selection
0: Potentiometer on keypad
1: Analog signal input. (AVI)
2: Analog signal input. (ACI)
3: Frequency set by
communication
2 - *1
10-02 PID target (keypad input) 0.0~100.0 50.0 % *1
10-03 PID mode selection
0: Disabled
1: Deviation D control.
FWD characteristic.
2: Feedback D control
FWD characteristic.
3: Deviation D control
reverse characteristic.
4: Feedback D control
reverse characteristic.
0 -
10-04 Feedback gain coefcient 0.00~10.00 1.00 % *1
10-05 Proportional gain 0.0~10.0 1.0 % *1
10-06 Integral time 0.0~100.0 10.0 sec *1
10-07 Derivative time
0.00~10.00 0.00 sec *1
10-08 PID offset
0: Positive
1: Negative
0 - *1
10-09 PID offset adjust 0~109 0 % *1
10-10 PID output lag lter time 0.0~2.5 0.0 sec *1
10-11 Feedback loss detection mode
0: Disabled
1: Enabled - drive continues to
operate after feedback loss
2: Enabled - drive “STOPS”
after feedback loss
10-12 Feedback loss detection leve 0~100 0 %
10-13 Feedback loss detection delay time 0.0~25.5 1.0 sec
10-14 Integration limit value 0~109 100 % *1
10-15
Integral value resets to zero when
feedback signal equals the target
value
0: Disabled
1: 1 Second
30: 30 Seconds (0 ~ 30)
0 -
10-16
Allowable integration error margin
(units) (1unit = 1/8192)
0~100 0 -
10-17 PID sleep frequency level 0.00~650.00 0.00 Hz
10-18 PID sleep function delay time 0.0~25.5 0.0 sec
10-19 PID wake up frequency level 0.00~650.00 0.00 Hz
10-20 PID wake up function delay time 0.0~25.5 0.0 sec
10-21 Max PID feedback setting 0~999 100 - *1
10-22 Min PID feedback setting 0~999 0 - *1
