CARLO GAVAZZI VariFlex3 RVLF Series Quick Start Guide

Specications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network.18/11/2014 27
Motor Controllers AC Variable Frequency Drives Type Variex
3
RVLF
Group 09 Communication function setup
No. Description Range
Factory
setting
Unit Note
09-00
Assigned communication station
number
1~32 1 - *2*3
09-01 RTU code/ASCII code select
0: RTU code
1: ASCII code
0 - *2*3
09-02 Baud rate setting (bps)
0: 4800
1: 9600
2: 19200
3: 38400
2 bps *2*3
09-03 Stop bit selection
0: 1 Stop bit
1: 2 Stop bits
0 - *2*3
09-04 Parity selection
0: Without parity
1: With even parity
2: With odd parity
0 - *2*3
09-05 Data format selection 0: 8-bits data 1: 7-bits data 0 - *2*3
09-06
Communication time-out detection
time
0.0~25.5 0.0 sec
09-07
Communication time-out operation
selection
0: Deceleration to stop
(00-15: deceleration time 1)
1: Coast to stop
2: Deceleration to stop
(00-17: deceleration time 2)
3: Continue operating
0 -
09-08 Error 6 verication time 1~20 3
09-09 Drive transmit delay time (ms) 5~65 5 ms
