Motor Controllers AC Variable Frequency Drives Type Variex
3
RVLF
Group 08 Drive & Motor protection functions
No. Description Range
Factory
setting
Unit Note
08-00 Trip prevention selection
xxxx0: Enable trip prevention
during acceleration
xxxx1: Disable trip prevention
during acceleration
xxx0x: Enable trip prevention
during deceleration
xxx1x: Disable trip prevention
during deceleration
xx0xx: Enable trip prevention in
run mode
xx1xx: Disable trip prevention
in run mode
x0xxx: Enable over voltage
prevention in run mode
x1xxx: Disable over voltage
prevention in run mode
00000 -
08-01
Trip prevention level during
acceleration (%)
50~200 200
Inverter
rated
current
100%
08-02
Trip prevention level
during deceleration (%)
50~200 200
08-03
Trip prevention level in run mode (%) 50~200 200
08-04
Over voltage prevention level in run
mode
350~390 380 VDC
08-05
Electronic motor overload protection
operation mode
0: Disable electronic motor
overload protection
1: Enable electronic motor
overload protection
1 -
08-06
Operation after overload protection is
activated
0: Coast-to-stop after overload
protection is activated
1: Drive will not trip when overload
protection is activated (OL1)
0 -
08-07
Over heat protection
(cooling fan control)
0: Auto (depends on temp.)
1: Operate while in RUN mode
2: Always run
3: Disabled
1 -
08-08
AVR function (auto voltage regulation)
0: AVR function enable
4 -
1: AVR function disable
2: AVR function disable for stop
3: AVR function disable for
deceleration
4: AVR function disable for
stop and deceleration.
5: When VDC>(360V/740V),
AVR function disable for stop
and deceleration.
08-09
Input phase lost
protection
0: Disabled
1: Enabled
0 -
