CARLO GAVAZZI VariFlex3 RVLF Series Quick Start Guide

Specications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network.18/11/2014 25
Motor Controllers AC Variable Frequency Drives Type Variex
3
RVLF
Group 07 Start/Stop command setup
No. Description Range
Factory
setting
Unit Note
07-00 Momentary power loss and restart
0: Momentary power loss and
restart disable
1: Momentary power loss and
restart enable
0 sec
07-01 Auto restart delay time 0.0~800.0 0.0 sec
07-02 Number of auto restart attempts 0~10 0 -
07-03 Reset mode setting
0: Enable reset only when run
command is off
1: Enable reset when run com-
mand is on or off
0 -
07-04 Direct running after power up
0: Enable direct run on power up
1: Disable direct run on power up
1 -
07-05 Delay-ON timer 1.0~300.0 1.0 sec
07-06
DC injection brake start frequency
(Hz) in stop mode
0.10~10.00 1.5 Hz
07-07
DC injection brake level (%) in stop
mode
0~20 5 %
07-08
DC injection brake time (seconds)
in stop mode
0.0~25.5 0.5 sec
07-09 Stopping method
0: Deceleration to stop
1: Coast to stop
0
Group 06 Auto run (Auto sequencer) function
No. Description Range
Factory
setting
Unit Note
06-34 Auto Run mode running direction 2
0: Stop
1: Forward
2: Reverse
0 -
06-35 Auto Run mode running direction 3 0 -
06-36 Auto Run mode running direction 4 0 -
06-37 Auto Run mode running direction 5 0 -
06-38 Auto Run mode running direction 6 0 -
06-39 Auto Run mode running direction 7 0 -
