18” CHIPPER MACHINE CONTROLS
23
BREAKAWAY SWITCH
• The breakaway switch is a safety device
designed to activate the chipper brakes if
it ever becomes uncoupled from the tow
vehicle. A cable attached to the
breakaway switch is attached to the tow
vehicle so that the breakaway switch will
separate and cause the brakes to be
applied to slow the chipper.
WINCH CONTROL VALVE
(OPTIONAL EQUIPMENT)
• Carlton Chippers may be equipped with
a hydraulic winch. The winch is used to
pull trees and brush that are too large to
carry to the chipper and to assist in
lifting the tree into the infeed tray.
BREAK AWAY SWITCH CONNECTED TO TOW VEHICLE
