Carnation CR1500 - Exterior

User Manual
4
♦Hopper with adjustable guides
♦Banknote
receiving wheel
Exterior
1. Front View
2. Rear view
♦Hopper
♦Banknote pressing wheel
♦Control panel
♦Reject pocket
♦LCD display
♦Banknote receiving sensor
♦Stacker
♦USB port for PC connection
♦RS232 port
♦SD card slot
♦Banknote rollers
♦Port for printer
♦Handle of back drawer
♦On/off switch
♦Power cord jack
♦ Adjusting screw
♦ Handle
♦Banknote receiving wheel
