Carrier 09PE - 5 Instructions for Lifting and Placing the Feet in the Operating Position and for Shipping; Lifting HORIZONTAL Units; Lifting VERTICAL Units

5 - INSTRUCTIONS FOR LIFTING AND PLACING THE FEET IN THE OPERATING
POSITION AND FOR SHIPPING
■ The weights are given on the data plates.
■ Attach the slings to the sling points indicated by the yellow labels.
■ We recommend fitting protection between the casing and the hooks to prevent damage to the paintwork.
■ Never lift horizontal units by the feet.
5.1 - Lifting HORIZONTAL units
■ The horizontal units marked in the table below with a (!) symbol must be lifted using a spreader beam.
Lifting using a spreader beam Lifting using a crane
A A A
B
B B


A = B
 < 60°
 > 60°
E
E
E
E
E
E
1067 1067 1067
HH
H
1023


5.2 - Lifting VERTICAL units
Lifting using a spreader beam Lifting using a crane
E E E
1067 1067 1067
H
H
H
1023


FMA
line number
FMA
number
A = B H
E
S module (950 mm) M module (1600 mm) L module (1900 mm)
1
1
1180 1375
950 (!) 1600 (!) 1900
2 1900 3200 3800 (!)
3 2850 4800 (!) 5700 (!)
4 3800 (!) 3200 3800 (!)
5 2850 4800 (!) 5700 (!)
6 1900 - -
2
4
2300 2495
1900 (!) 3200 (!) 3800
6 2850 (!) 4800 5700
8 3800 3200 (!) 3800
10 2850 (!) 4800 5700
12 1900 (!) 3200 (!) 3800
14 2850 (!) 4800 -
6
