Carrier 33CS - Page 8

TB
S1
S2
TO THERMOSTAT
RED
BLK
RED
RED
BLK
BLK
BLK
RED
BLK
RED
SENSOR 1 SENSOR 2 SENSOR 3 SENSOR 4
SPACE TEMPERATURE AVERAGING — 4 SENSOR APPLICATION
TB
S1
S2
RED
BLK
TO THERMOSTAT
RED
BLK
SENSOR 2
SENSOR 1
RED
RED
BLK
SENSOR 3
SENSOR 4
BLK
BLK
RED
RED
RED
BLK
BLK
SENSOR 8
SENSOR 9
SENSOR 5
RED
BLK
SENSOR 6
SENSOR 7
BLK
RED
SPACE TEMPERATURE AVERAGING — 9 SENSOR APPLICATION
Fig. 10 — Space Temperature Averaging
LEGEND
TB — Terminal Block
Factory Wiring
Field Wiring
8
