Carrier 33CSSP3-FC - Lockout and Outside Sensor Icons

Display
5
9 Start & Stop icon - Page 14 & 16
Appear when programming occupied time periods.
10 Locked icons - Pages 30
Indicates keypad has been locked.
11 Outside icons - Pages 21-31
Indicates the temperature displayed is from the optional outside sensor.
OUTSIDE
9
10
11
