MODEL NUMBER NOMENCLATURE
OUTDOOR UNIT
38 HDR 3---01
---
018
Air ---Cooled Condenser
Unit Type
HDR --- C o o l i n g O n l y
QRR --- H e a t P u m p
Voltage
3--- 208/230---1---60
5--- 208/230---3---60**
6--- 4 6 0 --- 3 --- 60 * *
Nominal Capacity
018 --- 1 --- 1 / 2 To n
024 --- 2 To n
030 --- 2 --- 1 / 2 To n
036 --- 3 To n s
048 --- 4 To n s
060 --- 5 To n s
INDOOR UNIT
40 QAC 3---01
---
018
Fan Coil Unit
Unit Type
QAC --- C o o l i n g O n l y
QAQ --- H e a t P u m p
Voltage
3 --- 208/230---1 ---60
Nominal Capacity*
024 --- 2 To n
036 --- 3 To n
048 --- 4 To n
060 --- 5 To n s
* For n ominal size 018 and 030, the indoor un it sizes 024 and 036 are matched with outdoor unit sizes 018 and 030 respectively.
** On sizes 036, 048 and 060
®
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
40QAC/38HDR -- 40QAQ/38QR
