SG-38MHRC-01 Specifications subject to change without notice. 55
DISASSEMBLY INSTRUCTIONS SIZE 24K (CONT)
Procedure Illustration
4) Remove the water collecting cover
screws (2) and then remove the water
collecting cover.
5) Remove the front panel screws
and then remove the front panel.
Water Collecting Cover
Front Panel
