122

APPENDIX V. M OTORMASTER SENSOR LOCATIONS (cont.)

C08263

Fig. 111 -- 50HC*A09 Outdoor Circuiting

CIRCUIT A CIRCUIT B

SENSOR

LOCATION

SENSOR

LOCATION

C12495

Fig. 112 -- 50HC*D14 Outdoor Circuiting (Circuit A and Circuit B)
