Carrier 50HC Series User Manual

47
FASTENER TORQUE VALUES
Table 11 – Torque Values
Supply fan motor mounting
120 in--- lbs (13.6 Nm)  12 in--- lbs (1.4Nm)
Supply fan motor adjustment plate
120 in--- lbs (13.6 Nm)  12 in--- lbs (1.4Nm)
Motor pulley setscrew
72 in--- lbs (8.1 Nm)  5in---lbs(0.6Nm)
Fan pulley setscrew
72 in--- lbs (8.1 Nm)  5in---lbs(0.6Nm)
Blower wheel hub setscrew
72 in--- lbs (8.1 Nm)  5in---lbs(0.6Nm)
Bearing locking collar setscrew 5 0 i n --- l b s ( 6 . 2 N m ) --- 6 0 i n --- l b s ( 6 . 8 N m )
Compressor mounting bolts 65 in--- lbs (7.3 Nm) ---75 in---lbs (8.5Nm)
Condenser fan motor mounting bolts
20 in--- lbs (2.3 Nm)  2 i n --- l b s 0 . 2 N m )
Condenser fan hub setscrew
84 in--- lbs (9.5 Nm)  12 in--- lbs (1.4 Nm)
