Carrier 50HC Series - Page 70

70
APPENDIX III. FAN PERFORMANCE (cont.)
X13 MULTI --SPEED/TORQUE MOTOR
Table 49 – Pulley Adjustment
UNIT Motor/Drive Combo
Motor Pulley turns open
0 0.5 1 1.5 2 2.5 3 3.5 4 4.5 5
04
1
Phase
Standard Static 854 825 795 766 736 707 678 648 619 589 560
Medium Static 1175 1135 1094 1054 1013 973 932 892 851 811 770
3
Phase
Standard Static* 854 825 795 766 736 707 678 648 619 589 560
Medium Static* 1175 1135 1094 1054 1013 973 932 892 851 811 770
High Static 1466 1423 1380 1337 1294 1251 1207 1164 1121 1078 1035
05
1
Phase
Standard Static 854 825 795 766 736 707 678 648 619 589 560
Medium Static 1175 1135 1094 1054 1013 973 932 892 851 811 770
3
Phase
Standard Static* 854 825 795 766 736 707 678 648 619 589 560
Medium Static* 1175 1135 1094 1054 1013 973 932 892 851 811 770
Medium Static 1303 1265 1226 1188 1150 1112 1073 1035 997 958 920
High Static 1550 1516 1482 1447 1413 1379 1345 1311 1276 1242 1208
06
1
Phase
Standard Static 1175 1135 1094 1054 1013 973 932 892 851 811 770
Medium Static 1466 1423 1380 1337 1294 1251 1207 1164 1121 1078 1035
3
Phase
Standard Static* 1175 1135 1094 1054 1013 973 932 892 851 811 770
Medium Static* 1466 1423 1380 1337 1294 1251 1207 1164 1121 1078 1035
High Static 1550 1525 1501 1476 1451 1427 1402 1377 1352 1328 1303
07
3
Phase
Standard Static 747 721 695 670 644 618 592 566 541 515 489
Medium Static 949 927 906 884 863 841 819 798 776 755 733
High Static 1102 1083 1063 1044 1025 1006 986 967 948 928 909
08
3
Phase
Standard Static 733 712 690 669 647 626 604 583 561 540 518
Medium Static 936 911 887 862 838 813 788 764 739 715 690
High Static 1084 1059 1035 1010 986 961 936 912 887 863 838
09
3
Phase
Standard Static 733 712 690 669 647 626 604 583 561 540 518
Medium Static 936 911 887 862 838 813 788 764 739 715 690
High Static 1084 1059 1035 1010 986 961 936 912 887 863 838
11
3
Phase
Standard Static 838 813 789 764 739 715 690 665 640 616 591
Medium Static 1084 1059 1035 1010 986 961 936 912 887 863 838
High Static 1240 1218 1196 1175 1153 1131 1109 1087 1066 1044 1022
12
3
Phase
Standard Static 838 813 789 764 739 715 690 665 640 616 591
Medium Static 1084 1059 1035 1010 986 961 936 912 887 863 838
High Static 1240 1218 1196 1175 1153 1131 1109 1087 1066 1044 1022
14
3
Phase
Standard Static 843 824 805 786 767 748 728 709 690 671 652
Medium Static 778 761 744 727 710 694 677 660 643 626 609
High Static 955 937 919 901 883 866 848 830 812 794 776
--- F a c t o r y s e t t i n g s
* Humidi--- MiZer models only
50HC
