Carrier 52VQR09 - Physical Data

5
HEATING RATINGS — 52VWR HOT WATER HEAT UNITS
Physical data
UNIT
AIR FLOW
(CFM)
GPM
PRESSURE
DROP (in. wg)
BTUH (x1000) AT ENTERING WATER TEMPERATURE
120 F 140 F 180 F
52VWR12
500
4 3.2 12.7 17.8 28.0
3 1.9 12.2 17.1 26.9
2 0.9 11.5 16.1 25.3
370
4 3.2 10.6 14.8 23.3
3 1.9 10.2 14.3 22.5
2 0.9 9.6 13.5 21.2
52VWR18
(2-Row Coil)
780
4 3.2 16.4 22.9 36.0
3 1.9 15.7 22.0 34.6
2 0.9 14.6 20.4 32.0
690
4 3.2 15.3 21.4 33.6
3 1.9 14.7 20.6 32.4
2 0.9 13.6 19.1 30.0
52VWR18
(3-Row Coil)
760
4 4.7 21.1 29.5 46.3
3 2.7 20.2 28.3 44.5
21.3 18.8 26.3 41.3
680
4 4.7 19.7 27.6 43.4
32.7 18.9 26.5 41.6
2 1.3 17.6 24.7 38.8
52VWR24
(2-Row Coil)
820
43.2 16.8 23.5 36.9
3 1.9 16.1 22.5 35.3
2 0.9 14.9 20.8 32.7
590
4 3.2 14.0 19.6 30.8
3 1.9 13.4 18.8 29.5
2 0.9 12.6 17.6 27.6
52VWR24
(3-Row Coil)
800
4 4.7 21.7 30.4 47.8
32.7 20.8 29.1 45.7
2 1.3 19.2 26.9 42.3
580
4 4.7 17.9 25.0 39.3
3 2.7 17.1 24.0 37.7
2 1.3 16.1 22.5 35.3
UNIT
SHIPPING WEIGHT (lb)
09 12 18 24
52VCR 245 245 255 255
52VER 245 245 255 255
52VQR 245 245 255 255
52VWR — 245 255 255
