8
DUCT OPENING
1
71-1/4
41-1/4
CONDENSER
OUTLET
CONDENSER
INLET
20
20
20
LOW
VOLTAGE
RETURN
AIR
SERVICE PULLOUT
ELECTRICAL
KNOCKOUT
BLOWER
MOTOR
12
3-3/4
1-1/2
3-3/4
2
16
12-3/4
FILTER
HOT WATER
INLET (1)
HOT WATER
COIL
52VWR12-24 COOLING WITH HOT WATER HEAT UNITS
a52-1342
NOTES:
1. Hot water coil connections are
7
/
8
-in. O.D. sweat.
2. Dimensions are in inches.
Base unit dimensions (cont)
