T-359 3–6
3.2 REFRIGERATION SYSTEM DATA
3.3 ELECTRICAL DATA
a. Compressor/Motor Assembly
Model Number ZMD26KVE-TFD-274
Weight (With Oil) 42.9 kg (95 lb)
Approved Oil Uniqema Emkarate RL-32-3MAF
Oil Charge 1774 ml (60 ounces)
b. Electronic Expansion Valve
Superheat (Evaporator)
Verify at -18C
(0F) container box
temperature
4.4 to 6.7C (8 to 12F)
c. Economizer Expansion Valve
Superheat
Verify at -18C
(0F) container box
temperature
4.4 to 11.1C (8 to 20F)
d. Heater Termination Thermostat
Opens 54 (+/- 3) C = 130(+/- 5) F
Closes 38 (+/- 4) C = 100 (+/- 7) F
e. High Pressure Switch
Cutout 25 (+/- 1.0) kg/cm
2
= 350 (+/- 10) psig
Cut-In 18 (+/- 0.7) kg/cm
2
= 250 (+/- 10) psig
CAUTION
!
Charge receiver according to nameplate specifications to ensure optimal unit performance.
f. Refrigerant Charge - R-134a Receiver 4.99 kg (11 lbs)
g. Fusible Plug
Melting point 99C = (210F)
Torque 6.2 to 6.9 mkg (45 to 50 ft-lbs)
h. Rupture Disc
Bursts at 35 +/-
5% kg/cm
2
= (500 +/- 5% psig)
Torque 6.2 to 6.9 mkg (45 to 50 ft-lbs)
i. Unit Weight Refer to unit model number plate.
a. Circuit Breaker CB-1 Trips at 29 amps
CB-2 (50 amp) Trips at 62.5 amps
CB-2 (70 amp) Trips at 87.5 amps
b. Compressor Motor Full Load Amps (FLA) 13 amps @ 460 VAC
c. Condenser Fan
Motor
380 VAC, Single Phase,
50 Hz
460 VAC, Single Phase,
60 Hz
Full Load Amps 1.3 amps 1.6 amps
Horsepower 0.43 hp 0.75 hp
Rotations Per Minute 1425 rpm 1725 rpm
Voltage and Frequency 360 - 460 VAC +/- 2.5 Hz 400 - 500 VAC +/- 2.5 Hz
Bearing Lubrication Factory lubricated, additional grease not required.
Rotation Counter-clockwise when viewed from shaft end.
