Carrier AquaForce B Series - MODES - Modes; SETPOINT - Setpoint Table

254
APPENDIX A — CARRIER CONTROLLER DISPLAY TABLES (cont)
* Depends on the selected language (English by default).
LEGEND
MODES — Modes
Carrier Controller PATH: Main Menu  Modes
LINE DISPLAYED TEXT* CCN NAME RANGE
DEFAULT
VALUE
UNIT
READ/
WRITE
1 Start Up Delay In Effect m_delay No(0)/Yes(1) No(0) — RO
2 Second Setpoint In Use m_2stpt No(0)/Yes(1) No(0) — RO
3 Reset In Effect m_reset No(0)/Yes(1) No(0) — RO
4 Demand Limit Active m_demlim No(0)/Yes(1) No(0) — RO
5 Evaporator Pump Rotation m_pmprot No(0)/Yes(1) No(0) — RO
6 Pump Periodic Start m_pmpper No(0)/Yes(1) No(0) — RO
7 Night Low Noise Active m_night No(0)/Yes(1) No(0) — RO
8 Master Slave Active m_slave No(0)/Yes(1) No(0) — RO
9 Ice Mode In Effect m_ice No(0)/Yes(1) No(0) — RO
10 Current Alarm 1 m_alarm1 — — — RO
11 Current Alarm 2 m_alarm2 — — — RO
12 Current Alarm 3 m_alarm3 — — — RO
13 Current Alarm 4 m_alarm4 — — — RO
14 Current Alarm 5 m_alarm5 — — — RO
SETPOINT — Setpoint Table
Carrier Controller PATH: Main Menu  Setpoint Table
LINE DISPLAYED TEXT* CCN NAME RANGE
DEFAULT
VALUE
UNIT
READ/
WRITE
1 Cooling Setpoint 1 csp1
-20 to 78.8(-28.89
to 26.00)
44(6.67) °F (°C) RW
2 Cooling Setpoint 2 csp2
-20 to 78.8(-28.89
to 26.00)
44(6.67) °F (°C) RW
3 Cooling Ice Setpoint ice_sp
-20 to 78.8(-28.89
to 26.00)
44(6.67) °F (°C) RW
4 Cooling Ramp Loading cramp_sp
0.1 to 20(0.06 to
11.11)
0.5(0.28) °F (°C) RW
5 Switch Limit Setpoint 1 lim_sp1 0 to 100 100 % RW
6 Switch Limit Setpoint 2 lim_sp2 0 to 100 100 % RW
7 Switch Limit Setpoint 3 lim_sp3 0 to 100 100 % RW
RO — Read Only
RW — Read/Write
