Carrier AquaForce B Series - NET_ETH0 - Network Conn-eth0; NET_ETH1 - Network Conn-eth1; CCN_CONF - CCN Configuration; BACCONF - BACNet Standard Configuration

257
APPENDIX A — CARRIER CONTROLLER DISPLAY TABLES (cont)
* Depends on the selected language (English by default).
† Points are RO unless the Configure Bar is selected at which time ALL
the points become RW.
NET_ETH0 — Network Conn-eth0
Carrier Controller PATH: Main Menu  Configuration Menu  HMI Configuration  Network Conn-eth0
LINE DISPLAYED TEXT* CCN NAME RANGE
DEFAULT
VALUE
UNIT
READ/
WRITE†
1 MAC address RO
2 IP address RO
3 Subnet Mask RO
4 Default Gateway RO
5 DNS Server1 RO
6 DNS Server2 RO
NET_ETH1 — Network Conn-eth1
Carrier Controller PATH: Main Menu  Configuration Menu  HMI Configuration  Network Conn-eth1
LINE DISPLAYED TEXT* CCN NAME RANGE
DEFAULT
VALUE
UNIT
READ/
WRITE†
1 MAC address RO
2 IP address RO
3 Subnet Mask RO
4 Default Gateway RO
5 DNS Server1 RO
6 DNS Server2 RO
CCN_CONF — CCN Configuration
Carrier Controller PATH: Main Menu  Configuration Menu  HMI Configuration  CCN Configuration
LINE DISPLAYED TEXT* CCN NAME RANGE
DEFAULT
VALUE
UNIT
READ/
WRITE†
1 CCN address 1RW
2 CCN Bus 0RW
3 Primary Bus Baud Rate
9600
19200
38400
9600 RW
BACCONF — BACNet Standard Configuration
Carrier Controller PATH: Main Menu  Configuration Menu  HMI Configuration  BACNet Configuration
LINE DISPLAYED TEXT* CCN NAME RANGE
DEFAULT
VALUE
UNIT
READ/
WRITE†
— BACnet Enable bacena
Disable(0)/
Enable(1)
Enable(1) — —
1 Metric Units bacunit No(0)/Yes(1) Yes(1) — RW
2 Network network 1 to 9999 1601 — RW
3 Identifier ident 0 to 9999999 1610101 — RW
4 BACnet Mgmt Device† bbmd 0 to 2 0 — RW
5 BACnet Data Link Layer XXXXX
MS/TP(0)/
BACnet IP(1)
XXXXX — RW
6 MS/TP MAC Address XXXXX XXXXX XXXXX — RW
7 MS/TP Baud Rate XXXXX XXXXX XXXXX — RW
8 Max Masters XXXXX XXXXX XXXXX — RW
9 MS/TP Max Info Frames XXXXX XXXXX XXXXX — RW
