4
ARI* capacity ratings
LEGEND
* Air Conditioning and Refrigeration Institute.
NOTE: Based on ARI-550/590 standard rating conditions. Ratings are for
standard chillers only. Ratings do not include options.
UNIT
30RA
CAPACITY
COMPRESSOR
POWER INPUT
(kW)
FAN
POWER
(kW)
TOTAL
POWER
(kW)
FULL LOAD IPLV
COOLER FLOW
RATE
COOLER
WATER
PRESSURE
DROP
Tons kW EER COP EER COP GPM L/s Ft wg kPa
010 9.6 33.7 9.7 1.9 11.7 9.8 2.9 12.9 3.8 22.9 1.4 5.6 16.7
015 13.7 48.1 14.8 1.9 16.8 9.8 2.9 12.8 3.7 33.0 2.1 6.8 20.3
018 15.9 55.9 18.0 1.9 20.0 9.6 2.8 13.4 3.9 38.2 2.4 7.5 22.4
022 21.1 74.2 23.4 1.7 25.2 10.0 2.9 14.1 4.1 50.6 3.2 9.7 29.0
025 23.8 83.6 27.9 1.7 29.7 9.6 2.8 13.9 4.1 57.1 3.6 10.7 32.0
030 27.2 95.6 31.7 1.7 33.5 9.8 2.9 14.0 4.1 65.3 4.1 12.6 37.7
035 34.8 122.3 37.8 3.6 41.5 10.1 2.9 14.5 4.2 83.4 5.3 7.7 23.0
040 37.7 132.5 42.8 3.6 46.6 9.7 2.8 13.6 4.0 90.6 5.7 8.2 24.5
045 43.1 151.5 47.5 3.4 51.1 10.1 3.0 15.2 4.4 103.4 6.5 11.2 33.5
050 47.4 166.6 55.8 3.4 59.4 9.6 2.8 14.1 4.1 113.8 7.2 12.1 36.2
055 54.3 190.8 63.4 3.4 67.0 9.7 2.8 14.1 4.1 130.4 8.2 14.3 42.7
COP — Coefficient of Performance
EER — Energy Efficiency Ratio
IPLV — Integrated Part Load Value
Model number nomenclature
Voltage
1–575-3-60
2–380-3-60
4–230-3-60
5–208/230-3-60
6–460-3-60
Compressor Start Option
N– Standard Across-the-Line Start
Packaging
1 – Standard Domestic (Coil Cover and
Bottom Skid)
3 – Standard Export with Coil Cover,
Top and Bottom Skid & Shipping Bag
4–Full Export Crate
5–Option #1 with Factory-Installed Coil Grilles
7–Option #
3 with Factory-Installed Coil Grilles
8 – Option #4 with Factory-Installed Coil Grilles
3 0 R A N 0 1 0 – – – 6 1 1 – –
38RA – Air-Cooled AquaSnap Chiller
Unit Sizes
010 025
040
055
015 030
018
045
022
035
050
Chilled Fluid Pump Options
–– No pump installed
A–Single Pump, 1.5 HP
B–Single Pump, 2 HP
C – Single Pump, 2 HP High Head
D–Single Pump, 3 HP
E–Single Pump, 5 HP
F–Dual Pump, 1.5 HP
G–Dual Pump, 2 HP
H–Dual Pump, 2 HP High Head
J–Dual Pump, 3 HP
K–Dual Pump, 5 HP
Factory-Installed Options (FIOP)
Series – 1
Display, Energy Management, GFI Option
––Standard Scrolling Marquee (SM) Display
E–SM + EMM
S – SM + EMM + GFI Convenience Outlet
(120 Volt, 4 Amp) [1,4,5,6 Voltages Only)
Condenser Coil Options
––Standard Copper Tube/Aluminum Fin
C– Copper Tube/Copper Fin, Copper Tube Sheet/Mylar
Coil Separator
E–Copper Tube/Aluminum Fin with E-Coat
F–Copper Tube/Copper Fin, Copper Tube Sheet,
Mylar Sep
arator with E-Coat
K– Copper Tube/Aluminum Fin Precoated
AQUASNAP
®
CHILLER MODEL NUMBER DESIGNATION
LEGEND
EMM — Energy Management Module
GFI — Ground Fault Interrupting
Quality Assurance
Certified to ISO 9001: 2000
a30-4595
