17
REFRIGERATION CYCLE DI AGRAM
CAPILLARY TUBE
HEAT
EXCHANGER
(CONDENSER)
HEAT
EXCHANGER
(EVAPORATOR)
FIELD
PIPING
COMPRESSOR
FLARE CONNECTION
SERVICE VALVE
SERVICE VALVE W/GUAGE PORT
TWO PHASE LIQUID LINE
SUCTION LINE
FIELD
PIPING
FLARE CONNECTION
A08104
Fig. 13 – Cooling
CAPILLARY TUBE
HEAT
EXCHANGER
(CONDENSER)
HEAT
EXCHANGER
(EVAPORATOR)
SERVICE VALVE
LIQUID HTG
LIQUID
TWO PHASE
CHECK VALVE
(HEATING MODEL ONLY)
REVERSING
VALVE
(HEAT PUMP ONLY)
COOLING
HEATING
COMPRESSOR
SUCTION
DISCHARGE
SUCTION
ACCUMULATOR
SERVICE VALVE
W/ GUAGE PORT
FIELD
PIPING
INDOOR UNIT OUTDOOR UNIT
FLARE CONNECTION
FLARE CONNECTION
A08105
Fig. 14 – Heat Pumps
38/40MVC, MVQ
