CHART 11 -- OUTDOOR MOTOR
Trace connections from
OD board. Connections
ok?
Motor ok.
Fix connection
No
Yes
Yes
No
Replace capacitors
Yes
No
Replace motor
Check capacitor.
Capacitor ok?
Check motor windings.
Ok?
Visually confirm that fan
blades and outdoor coil
are not blocked.
Clear blockage
Yes
No
Trace connections from
OD board. Connections
ok?
Motor ok.
Fix connection
No
Yes
Yes
No
Replace capacitors
Yes
No
Replace motor
Check capacitor.
Capacitor ok?
Check motor windings.
Ok?
Visually confirm that fan
blades and outdoor coil
are not blocked.
Clear blockage
Yes
No
A08172
38/40MVC, MVQ
