40
A 3 -- 5 3 M V C 0 1 2 -- -- -- 3
3 8 M V C 0 1 2 --- --- --- 3 C O N T R O L B O A R D
CONNECTOR INPUT or OUTPUT VALUE
CN2 OUT: (Pin 1: Pulse 0 to 12 Volts DC) (Pin2: 35±2 Volts DC) (Pin 3: GND) (Pin 4: 13±4 Volts DC) all relative to Pin 3
CN3 OUT: L2 208/230 Volt AC
CN4 IN : L2 208/230 Volt AC
CN9 OUT: L1 208/230 Volt AC
CN10 IN: L1 208/230 Volt AC
P1 Ground
P2 Ground
4 0 M V C 0 1 2 --- --- --- 3 C O N T R O L B O A R D
CONNECTOR INPUT or OUTPUT VALUE
CN1 I N : 0 --- 5 V o l t D C
CN2 I N : 0 --- 5 V o l t D C
CN3 Pulse drive output: 0--- 17 Volts DCPin 5: GND All other Pins are 0 to 17 Volt DC) All relative to Pin 5)
CN5
Power O utput: (Pin 1: GND) (Pin 2: 5 Volts DC) Input: (Pin 3: Pulse 0 to 5 Volts DC) Output:(Pin 4~ Pin 10: Pulse 0 to 5
Volt DC) All relative to Pin 1
CN6
Out: (Pin 1: 35 Volt DC) ( Pin 2: Empty) (Pin 3: GND) (Pin 4: 5 Volt DC) (Pin 5: Pulse 0--- 5 Volt DC) IN : (Pin 6: Pulse 0 to 5
Volt DC) All relative to Pin 3
G1 IN: (Pin 1: Pulse 0 to 12 Volts DC) (Pin2: 35±2 Volts DC) (Pin 3: GND) (Pin 4: 13±4 Volts DC) all relative to Pin 3
A 4 -- 5 3 M V Q 0 1 2 -- -- -- 3
3 8 M V Q 0 1 2 --- --- --- 3 C O N T R O L B O A R D
CONNECTOR INPUT or OUTPUT VALUE
CN1 OUT: (Pin 1: GND, Pin 2: 5 Volts DC, Pin 3: Empty) IN: (Pin 4: 0 to 5 Volts DC) All relative to Pin 1
CN2 OUT: (Pin 1: Pulse 0 to 12 Volts DC) (Pin2: 35±2 Volts DC) (Pin 3: GND) (Pin 4: 13±4 Volts DC) all relative to Pin 3
CN3 OUT: L2 208/230 Volt AC
CN4 IN : L2 208/230 V olt AC
CN5 OUT: L1 208/230 Volt AC
CN6 OUT: L1 208/230 Volt AC
CN10 IN: L1 208/230 Volt AC
P1 Ground
P2 Ground
4 0 M V Q 0 1 2 --- --- --- 3 C O N T R O L B O A R D
CONNECTOR INPUT or OUTPUT VALUE
CN1 I N : 0 --- 5 V o l t D C
CN2 I N : 0 --- 5 V o l t D C
CN3 Pulse drive output: 0--- 17 Volts DCPin 5: GND All other Pins are 0 to 17 Volt DC) All relative to Pin 5
CN5
Power O utput: (Pin 1: GND) (Pin 2: 5 Volts DC) Input: (Pin 3: Pulse 0 to 5 Volts DC) Output:(Pin 4~ Pin 10: Pulse 0 to 5
Volt DC) All relative to Pin 1
CN6
Out: (Pin 1: 35 Volt DC) ( Pin 2: Empty) (Pin 3: GND) (Pin 4: 5 Volt DC) (Pin 5: Pulse 0--- 5 Volt DC) IN : (Pin 6: Pulse 0 to 5
Volt DC) All relative to Pin 3
G1 IN: (Pin 1: Pulse 0 to 12 Volts DC) (Pin2: 35±2 Volts DC) (Pin 3: GND) (Pin 4: 13±4 Volts DC) all relative to Pin 3
38/40MVC, MVQ
