High Wall Type
Installation Manual
–23–
Adjustment of air direction
1. Using the remote control, change the up/
down air direction by moving the horizontal
louver.
2. Adjust the right/left air direction by bending
the vertical grille inside of the air outlet port
with hands.
REQUIREMENT
Do not touch the horizontal louver directly with
hands; otherwise a trouble may be caused.
For handling of the horizontal louver, refer to
“Owner’s Manual” attached to the indoor unit.
Group control
In a group control, a remote control can control up
to maximum 8 units.
• The wired remote control only can control a
group control. The wireless remote control is
unavailable for this control.
• For wiring procedure and wires of the individual
line (Identical refrigerant line) system, refer to
“Electric work” in this Manual.
• Wiring between indoor units in a group is
performed in the following procedure.
• Connect the indoor units by connecting the
remote control wires from the remote control
terminal blocks (A, B) of the indoor unit
connected with a remote control to the remote
control terminal blocks (A, B) of the other indoor
unit. (Non-polarity)
• For address setup, refer to the Installation
Manual attached to the outdoor unit.
23-EN
