3 - PHYSICAL DATA
30SZ/SZV 004 005 006 007 009 011 018 024 027 036
Nominal cooling capacity
30SZ* kW 14.60 16.10 19.50 22.90 27.90 33.50 56.00 78.00 85.00 112.00
30SZV** kW 13.70 15.40 18.50 22.10 26.40 32.30 52.00 72.00 77.00 106.00
Operating weight
30SZ kg 105 110 116 144 168 182 424 480 492 530
30SZV kg 94 98 102 129 150 162 390 441 448 475
Refrigerant charge*** R-407C
30SZ kg 1.5 1.6 2.20 2.16 2.30 2.97 8.10 9.00 10.20 11.60
Compressor type Scroll Semi-hermetic
No. of control steps 1111112222
Capacity control % - - - - - - 50-100 66-100 66-100 66-100
Evaporator type (30SZ/SZV) Plate heat exchanger
Net water volume l 1.23 1.42 1.71 1.90 2.37 2.85 4.70 5.60 6.60 8.40
Water connections MPT gas
Inlet-outlet in 1-1/4 1-1/4 1-1/4 1-1/4 1-1/4 1-1/4 1-1/2 1-1/2 1-1/2 1-1/2
Max. water pressure kPa 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
Condenser type (30SZ) Plate heat exchanger
Net water volume l 1.23 1.42 1.71 1.90 2.37 2.85 4.70 5.60 6.60 8.40
Water connections MPT gas
Inlet-outlet in 1-1/4 1-1/4 1-1/4 1-1/4 1-1/4 1-1/4 1-1/2 1-1/2 1-1/2 1-1/2
Max. water pressure kPa 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
* Evaporator entering water temperature 12°C, evaporator leaving water temperature 7°C, condenser entering water temperature 30°C,
condenser leaving water temperature 35°C.
** Evaporator entering water temperature 12°C, evaporator leaving water temperature 7°C; condensing temperature dewpoint 50°C.
*** The 30SZV units have a nitrogen holding charge only.
4 - ELECTRICAL DATA
30SZ 004 005 006 007 009 011 018 024 027 036
Nominal power supply V-ph-Hz 400-3-50
Voltage range V 360-440
Nominal unit power input* kW 3.88 4.06 6.03 7.03 7.33 9.89 15.70 23.70 25.80 36.30
Nominal unit current drawn* A 6.85 6.95 10.75 12.45 13.70 15.70 25.50 34.00 38.45 54.95
Maximum unit power input** kW 5.34 6.19 8.51 10.00 10.87 13.31 19.58 26.50 29.83 42.66
Maximum unit current drawn** A 9.05 9.70 14.10 16.50 18.00 21.16 33.30 42.55 53.10 70.10
Starting current A 59.5 70.5 94.0 116.0 127.0 159.0 104.0 134.0 152.0 207.0
30SZV 004 005 006 007 009 011 018 024 027 036
Nominal power supply V-ph-Hz 400-3-50
Voltage range V 360-440
Nominal unit power input† kW 4.14 4.43 6.36 7.32 8.02 10.70 16.40 23.80 26.10 36.70
Nominal unit current drawn† A 7.65 7.75 11.70 13.50 15.45 17.50 27.90 36.35 41.40 58.80
Maximum unit power input‡ kW 4.44 5.10 6.77 7.53 9.29 11.34 18.18 24.23 26.58 37.77
Maximum unit current drawn‡ A 9.05 9.70 14.10 16.50 18.00 21.16 33.30 42.55 53.10 70.10
Starting current A 59.5 70.5 94.0 116.0 127 159.0 104.0 134.0 152.0 207.0
* Evaporator entering water temperature 12°C, evaporator leaving water temperature 7°C, condenser entering water temperature 30°C,
condenser leaving water temperature 35°C.
** Evaporator leaving water temperature 10°C, condenser entering water temperature 50°C, condenser leaving water temperature 55°C.
† Evaporator entering water temperature 12°C, evaporator leaving water temperature 7°C, condensing temperature dewpoint 50°C.
‡ Evaporator leaving water temperature 10°C, condensing temperature dewpoint 60°C.
Electrical data notes
• 30SZ/SZV* units have a single power connection point.
• The control box includes the following standard features:
- the start-up and motor protection devices for each compressor.
- the control devices
• Field connections:
All connections to the system and the electrical installations must be in full
accordance with all applicable local codes.
• The Carrier 30SZ/SZV units are designed and built to ensure con-formance
with these codes. The recommendations of European standard EN 60204-1
(corresponding to IEC 60204-1)-(machine safety - electrical machine compo-
nents - part 1: general regulations) are specifically taken into account, when
designing the electrical equipment.
Notes:
• Conformance with EN 60204-1 is the best means of ensuring compliance with
the Machines Directive § 1.5.1. Generally the recommendations of IEC 60364
are accepted as compliance with the requirements of the installation
directives.
• Annex B of EN 60204-1 describes the electrical characteristics used for the
operation of the machines.
1. The operating environment for 30SZ/SZV units is specified below:
• Environment* - Environment as classified in EN 60634 § 3:
- ambient temperature range: +5°C to +40°C, class AA4*
- humidity range (non condensable)*:
50% rh at 40°C
90% rh at 20°C
- altitude:
£
2000 m
- indoor installation*
- presence of water, class AD2* (possibility of water drops)
- presence of hard solids, class AE2* (no significant dust present)
- presence of corrosive and polluting substances, class AF1 (negligible)
- vibration and shock, class AG2 , AH2
- Competence of personnel, class BA4* (personnel trained in accordance
with IEC 60364)
2. Power supply frequency variation: ± 2 Hz.
3. The neutral (N) line must not be connected directly to the unit (if necessary
use a transformer).
4. Overcurrent protection of the power supply conductors is not provided with the
unit.
5. The factory-installed disconnect switch(es) is (are) of a type suitable for power
interruption in accordance with EN 60947-3 (corresponding to IEC 60947-3).
6. The units are designed for connection to TN networks (IEC 60364). For IT
networks the earth connection must not be at the network earth. Provide a
local earth, consult competent local organisations to complete the electrical
installation.
NOTE: If particular aspects of an actual installation do not conform to the
conditions described above, or if there are other conditions which should be
considered, always contact your local Carrier representative.
* The required protection level for this class is IP21B (according to reference
document IEC 60529). All 30SZ/SZV units are protected to IP23C and fulfil this
protection condition.
