Table 9 — Condenser Fan Electrical Data
LEGEND
FLA — Full Load Amps
UNIT 30GXN,R
NAMEPLATE VOLTAGE
(V-Hz) (3-Phase)
STANDARD/LOW NOISE CONDENSER FAN HIGH STATIC CONDENSER FAN
Total Quantity FLA (ea) Total Quantity FLA (ea)
080, 090
208/230-60 4 7.5 4 14.6
230-60 4 7.5 4 14.6
460-60 4 3.4 4 6.3
575-60 4 2.7 4 5.2
380-60 4 4.1 4 7.4
083, 093, 108
106, 125, 135,
390B
208/230-60 6 7.5 6 14.6
230-60 6 7.5 6 14.6
460-60 6 3.4 6 6.3
575-60 6 2.7 6 5.2
380-60 6 4.1 6 7.4
114
208/230-60 6 7.5 6 14.6
230-60 6 7.5 6 14.6
460-60 6 3.4 6 6.3
575-60 6 2.7 6 5.2
380-60 6 4.1 6 7.4
118, 128, 138,
283B, 303B, 373B
150, 160, 370B, 415B
208/230-60 8 7.5 8 14.6
230-60 8 7.5 8 14.6
460-60 8 3.4 8 6.3
575-60 8 2.7 8 5.2
380-60 8 4.1 8 7.4
174, 204, 225, 370A,
450A/B, 475B
208/230-60 10 7.5 10 14.6
230-60 10 7.5 10 14.6
460-60 10 3.4 10 6.3
575-60 10 2.7 10 5.2
380-60 10 4.1 10 7.4
153, 283A, 328B,
393B, 418B
208/230-60 10 7.5 10 14.6
230-60 10 7.5 10 14.6
460-60 10 3.4 10 6.3
575-60 10 2.7 10 5.2
380-60 10 4.1 10 7.4
249, 475A, 500A/B
208/230-60 12 7.5 12 14.6
230-60 12 7.5 12 14.6
460-60 12 3.4 12 6.3
575-60 12 2.7 12 5.2
380-60 12 4.1 12 7.4
163, 178, 303A,
328A, 353A/B
208/230-60 12 7.5 12 14.6
230-60 12 7.5 12 14.6
460-60 12 3.4 12 6.3
575-60 12 2.7 12 5.2
380-60 12 4.1 12 7.4
264, 390A, 415A,
525A/B
208/230-60 12 7.5 12 14.6
230-60 12 7.5 12 14.6
460-60 12 3.4 12 6.3
575-60 12 2.7 12 5.2
380-60 12 4.1 12 7.4
208, 228,
453A/B, 478B
208/230-60 14 7.5 14 14.6
230-60 14 7.5 14 14.6
460-60 14 3.4 14 6.3
575-60 14 2.7 14 5.2
380-60 14 4.1 14 7.4
253, 268,
373A, 393A, 418A,
478A, 503A/B,
528A/B
208/230-60 16 7.5 14 14.6
230-60 16 7.5 14 14.6
460-60 16 3.4 14 6.3
575-60 16 2.7 14 5.2
380-60 16 4.1 14 7.4
281
460-60 16 3.4 16 6.3
575-60 16 2.7 16 5.2
380-60 16 4.1 16 7.4
301
460-60 16 3.4 16 6.3
575-60 16 2.7 16 5.2
380-60 16 4.1 16 7.4
325
460-60 16 3.4 16 6.3
575-60 16 2.7 16 5.2
380-60 16 4.1 16 7.4
350
460-60 16 3.4 16 6.3
575-60 16 2.7 16 5.2
380-60 16 4.1 16 7.4
