39
SERVICE CONFIGURATION (cont)
RTU Properties
Menu>
Startup Wizard
N/A System Space AQ system_iaq Properties>
Control Program>
Configuration>
Service
Configuration
N/A System Outdoor AQ system_oaq
N/A System Cool Demand
Level
cool_demand_level 0-3 0
N/A System Heat Demand
Level
heat_demand_level 0-3 0
N/A System Outdoor Air
Temperature
system_oat
System Fire/Smoke off/on off
3 Economizer High OAT
Lockout Temp
oat_ec_lockout 55-80°F 75
Equipment Touch
Only
3 Vent Dmpr Pos / DCV
Min Pos
econ_min 0-100% Open 20
3 Economizer Purge Min
Pos
econ_purge_min 0-100% Open 40
3 Low Fan Econ Min Pos econ_min_2 0-100% Open 33
3 DCV Max Vent Damper
Pos
iaq_dpr_max 0-75% Open 50
3 HP Rev Cycle Lockout
Temp
hp_rev_cycle_lockout -20 to 30°F -3
3 Occupancy Source occ_source 1=Always Occupied
2=BACnet Schedule
3=BAS On/Off
4=Remote Occ Input
Always Occupied
SERVICE TEST
Field Assistant Only
Service Test test_enable Disable/Enable Disable Properties>
Control Program>
Configuration>
Service
Configuration>
Service Test
Fan Test fan_test Disable/Enable Disable
High Speed Fan Test hi_spd_test Disable/Enable Disable
Compressor 1 Test comp1_test Disable/Enable Disable
Compressor 2 Test comp2_test Disable/Enable Disable
Heat 1 Test heat1_test Disable/Enable Disable
Heat 2 Test heat2_test Disable/Enable Disable
Reversing Valve Test rev_vlv_test Disable/Enable Disable
Dehumidification Test dehum_test Disable/Enable Disable
Power Exhaust Test pexh_test Disable/Enable Disable
Economizer Test econ_test 0-100% Open 0
VFD Speed Test vfd_spd_test 0-100% or 0-10vdc 0
UNIT MAINTENANCE
RTU Properties
Menu>
Maintenance
(Unit)
3 Occupancy Status occ_status Occupied/Unoccupied Properties>
Control Program
Maintenance>
Unit
N/A Temp Compensated
Start
-Or-
Learning Adaptive
Start
tcs_status
-Or-
aos_status
Inactive/Active
3 Pre Occupancy Purge purge Inactive/Active
N/A Space Temp Sensor spt_status 1=Sensor Failure
2=SPT Sensor
3=T55/T56
4=Network
5=Airside Linkage
6=Locked Value
3 Setpoint Adjustment stpt_adj xx°F
3 Effective Heat Setpoint effective_ht_stpt 0-120°F
3 Effective Cool Setpoint effective_ci_stpt 0-120°F
Table A — User Interface Menus (cont)
Equipment
Touch Menu
Access
Level
3=ADMIN
2=USER
1=No PW
POINT NAME BACnet Object RANGE DEFAULT
Field Assistant
Menu
APPENDIX A — USER INTERFACE MENUS (CONT)
