Carrier RTU Open User Manual

42
ALARMS (cont)
RTU Properties
Menu>
Alarms
3, 2, 1 Wireless Batter
Strength Alarm
Normal/Alarm Properties>
Control Program>
Alarms
3, 2, 1 Wireless Signal
Strength Alarm
Normal/Alarm
3, 2, 1 Supply Air Temperature sat_alarm Normal/Alarm
3, 2, 1 Supply Air Temp
Sensor
loc_sat_sensor_fail Normal/Alarm
N/A Supply Fan Failure sfan_fail_alarm Normal/Alarm
3, 2, 1 Supply Fan in Hand sfan_hand_alarm Normal/Alarm
3, 2, 1 Indoor Air Quality iaq_alarm Normal/Alarm
3, 2, 1 Indoor Air Quality
Sensor
iaq_sensor_alarm Normal/Alarm
3, 2, 1 Space Relative
Humidity
sprh_hi_alarm Normal/Alarm
3, 2, 1 Space Relative
Humidity Sensor
sprh_sensor_fail Normal/Alarm
3, 2, 1 Filter filter_alarm Clean/Dirty
3, 2, 1 Local OAT Sensor loc_oat_sensor_fail Normal/Alarm
3, 2, 1 Outdoor Air Temp
Sensor
oat_fail Normal/Alarm
3, 2, 1 Economizer Operation econ_opr Normal/Alarm
3, 2, 1 Economizer Normal
Failed to Fully Open
Failed to Open
Failed to Close
Stuck Open
3, 2, 1 Outdoor Air Quality
Sensor
oaq_fail Normal/Alarm
3, 2, 1 Setpoint Slider slidepot_alarm Normal/Alarm
3, 2, 1 Switch Configuration di_cfg_alarm Normal/Alarm
3, 2, 1 Analog Input
Configuration
ai_cfg_alarm Normal/Alarm
3, 2, 1 Supply Fan Runtime sfan_rntm_alarm Normal/Alarm
3, 2, 1 Compressor 1 Runtime comp1_rntm_alarm Normal/Alarm
3, 2, 1 Compressor 2 Runtime comp2_rntm_alarm Normal/Alarm
3, 2, 1 Airside Linkage Alarm air_linkage_fail Normal/Alarm
AIRSIDE LINKAGE
RTU Properties
Menu>
Maintenance
(Airside
Linkage)
N/A Linkage Collector link_collector Properties>
Control Program
Maintenance>
Airside Linkage
3 Airside Linkage Status a_link_status Not Active/Active
N/A Air Source Mode link_ahu_mode 1=Off
2=Warmup
3=Heating
4=Cooling
5=Freecool
6=Pressure
7=EVAC
8=Vent
N/A Air Source Supply Air
Temp
link_sat xxx°F
N/A Air Source Outdoor Air
Temp
link_ahu_oat xxx°F
N/A Number of Providers link_collector/4602 xx
N/A Occupancy Status link_occ Unoccupied/Occupied
N/A Space Temperature link_stp xxx°F
N/A Occupied Cooling
Setpoint
link_occ_cl_stpt 55-80°F
N/A Occupied Heating
Setpoint
link_occ_Ht_stpt 55-80°F
Table A — User Interface Menus (cont)
Equipment
Touch Menu
Access
Level
3=ADMIN
2=USER
1=No PW
POINT NAME BACnet Object RANGE DEFAULT
Field Assistant
Menu
APPENDIX A — USER INTERFACE MENUS (CONT)
