Carrier RTU Open User Manual

43
AIRSIDE LINKAGE (cont)
RTU Properties
Menu>
Maintenance
(Airside
Linkage)
N/A Unoccupied Cooling
Setpoint
link_unocc_cl_stpt 75-130°F Properties>
Control Program
Maintenance>
Airside Linkage
N/A Unoccupied Heating
Setpoint
link_unocc_ht_stpt 55-85°F
N/A Indoor Air CO2 (ppm) link_iaq xxx ppm
N/A Space Relative
Humidity
link_sprh xxx%
N/A Linkage Max Damper
Position
link_max_dmpr 0-100%
N/A Linkage Optimal Start a_link_opt_start Inactive/Active
1 This point is only visible when Input 3, 5, 8, or 9 is configured for Fan Status
2 This point will be hidden from view if Unit Type is configured for LC WeatherExpert
3 This point is only visible when Fan Control is configured for Variable Speed
4 This point is only visible when Fan Control is configured for Two Speed
5 This point is only visible when Unit Type is configured for HP O/B Ctrl or HP Y1/W1 Ctr
6 This point is hidden from view when Continuous Occupied Exhaust is enabled
7 This menu is hidden from view when RH Control is set to Disable
8 This menu is hidden from view when DCV Control is set to Disable
9 This point is visible when Fan Control is configured for Variable Speed and not LC WeatherExpert
10 These points are not visible when unit type is configured for LC WeatherExpert
11 This point is visible when Unit Type is configured for HP O/B Ctrl
Table A — User Interface Menus (cont)
Equipment
Touch Menu
Access
Level
3=ADMIN
2=USER
1=No PW
POINT NAME BACnet Object RANGE DEFAULT
Field Assistant
Menu
APPENDIX A — USER INTERFACE MENUS (CONT)
