Carrier RTU Open User Manual

47
Factory Test Relay 3 Control R/W
0=Off
1=On
Inactive (0) relay3_fac_test BV:91003
Factory Test Relay 4 Control R/W
0=Off
1=On
Inactive (0) relay4_fac_test BV:91004
Factory Test Relay 5 Control R/W
0=Off
1=On
Inactive (0) relay5_fac_test BV:91005
Factory Test Relay 6 Control R/W
0=Off
1=On
Inactive (0) relay6_fac_test BV:91006
Factory Test Relay 7 Control R/W
0=Off
1=On
Inactive (0) relay7_fac_test BV:91007
Factory Test Relay 8 Control R/W
0=Off
1=On
Inactive (0) relay8_fac_test BV:91008
Filter Status R
0=Clean
1=Dirty
filter_status BV:1004
Fire Shutdown Status R
0=Run Enabled
1=Shutdown
firedown_status BV:1005
Heat 1Test R/W
0=Disable
1=Enable
Inactive (0) heat1_test BV:81003
Heat 2Test R/W
0=Disable
1=Enable
Inactive (0) heat2_test BV:81002
Heat Stage 1 Relay State R
0=Off
1=On
heat_1 BV:2003
Heat Stage 2 Relay State R
0=Off
1=On
heat_2 BV:2002
Heat Type R/W
0=Electric
1=Gas
Inactive (0) heat_type BV:99002
High Speed Fan Test R/W
0=Disable
1=Enable
Inactive (0) hi_spd_test BV:81010
Humidistat Input Status R
0=High
1=Low
humstat_status BV:1006
IGC Override R
0=Off
1=Active
igcovr_status BV:1022
Local OAT Sensor R
0=Normal
1=Alarm
loc_oat_sensor_fail BV:7003
Occupancy Contact R
0=Off
1=On
occ_contact_status BV:1007
Power Exhaust Relay State R
0=Off
1=On
pexh BV:2010
Power Exhaust Test R/W
0=Disable
1=Enable
Inactive (0) pexh_test BV:81008
Reset Comp 1 Runtime Alarm R/W
0=Run
1=Clear
Inactive (0) comp1_rntm_clr BV:7514
Reset Comp 2 Runtime Alarm R/W
0=Run
1=Clear
Inactive (0) comp2_rntm_clr BV:7515
Reset Supply Fan Runtime
Alarm
R/W
0=Run
1=Clear
Inactive (0) sfan_rntm_clr BV:7510
Reversing Valve Output R/W Inactive (0) rev_vlv_type BV:1026
RH Control R/W Inactive (0) rh_enable BV:1025
Safety Chain Feedback R
0=Off
1=On
safety_status BV:1009
Schedule R/W
0=Unoccupied
1=Occupied
0 schedule BV:8000
Service Test R/W
0=Disable
1=Enable
Inactive (0) test_enable BV:81000
Setpoint Slider R
0=Normal
1=Alarm
slidepot_alarm BV:7002
Shutdown R/W
0=Inactive
1=Active
Inactive (0) shutdown BV:9001
Supply Fan Failure R
0=Normal
1=Alarm
sfan_fail_alarm BV:7008
Supply Fan in Hand R
0=Normal
1=Alarm
sfan_hand_alarm BV:7009
Supply Fan Runtime R
0=Normal
1=Alarm
sfan_rntm_alarm BV:7010
Table B — Network Points List for BACnet and Modbus (cont)
Point Name
Point
Access
Units
Default
Value
BACnet Info Modbus Info
BACnet
Point Name
BACnet
Object ID
Modbus
Register Type
Modbus
Register #
APPENDIX B — NETWORKPOINTS LIST FOR RTU OPEN (CONT)
