Switch Configuration R
0=Normal
1=Alarm
di_cfg_alarm BV:7025
System is shut down R
0=No
1=Yes
shutdown_status BV:2011
Unocc Free Cool R/W
0=Disable
1=Enable
Inactive (0) ntfc_ena BV:80001
Air Source Mode R
1=Off
2=Warmup
3=Heating
4=Cooling
5=Freecool
6=Pressure
7=Evac
8=Vent
link_ahu_mode MSV:2005
Compressor Stages R/W
1=One Stage
2=Two Stages
2 comp_stages MSV:91003
Equipment Status R
1=Disabled
2=Test 3=Run
mode_status MSV:2001
Fan Control R/W
1=Single Speed
2=Two Speed
3=Variable Speed
3 fan_type MSV:9031
Fan Mode R/W
1=Auto
2=Continuous
3=Always On
2 fan_mode MSV:9032
Input 1 Function R/W
1=No Sensor
2=IAQ Sensor
3=OAQ Sensor
4=Space RH Sensor
1 ai1_function MSV:81001
Input 2 Function R/W
1=No Sensor
2=IAQ Sensor
3=OAQ Sensor
4=Space RH Sensor
1 ai2_function MSV:81002
Input 3 Function R/W
1=No Function
2=Compressory
Safety
3=Fan Status
4=Filter Status
5=Remote
Occupancy
6=Door Contact
2 di3_function MSV:81003
Input 3 Switch Configuration R/W
1=NO
2=NC
1 di3_type MSV:81013
Input 5 Function R/W
1=No Function
2=Fire Shutdown
3=Fan Status
4=Filter Status
5=Remote
Occupancy
6=Door Contact
2 di5_function MSV:81005
Input 5 Switch Configuration R/W
1=NO
2=NC
1 di5_type MSV:81015
Input 8 Function R/W
1=No Function
2=Enthalpy Switch
3=Fan Status
4=Filter Status
5=Remote
Occupancy
6=Door Contact
2 di8_function MSV:81008
Input 8 Switch Configuration R/W
1=NO
2=NC
1 di8_type MSV:81018
Input 9 Function R/W
1=No Function
2=HumidiStat
3=Fan Status
4=Filter Status
5=Remote
Occupancy
6=Door Contact
2 di9_function MSV:81009
Input 9 Switch Configuration R/W
1=NO
2=NC
1 di9_type MSV:81019
Number Of Heat Stages R/W
1=1
2=2
3=0
2 heat_stages MSV:91004
Table B — Network Points List for BACnet and Modbus (cont)
Point Name
Point
Access
Units
Default
Value
BACnet Info Modbus Info
BACnet
Point Name
BACnet
Object ID
Modbus
Register Type
Modbus
Register #
APPENDIX B — NETWORKPOINTS LIST FOR RTU OPEN (CONT)
