2. Determine unit location (from project plans) or select unit
location.
3. Check for possible overhead obstructions which may
interfere with unit lifting or rigging.
Fig. 1 — 48TC**07-16 Units Model Number Nomenclature
Model Series - WeatherMaker
®
TC - Standard Efficiency
Unit Heat Type
48 - Gas Heat Packaged Rooftop
Cooling Tons
07 = 6 tons
08 = 7.5 tons
09 = 8.5 tons
12 = 10 tons
14 = 12.5 tons
16 = 15 tons
Heat Options
D = Low Heat
E = Medium Heat
F = High Heat
S = Low Heat w/ Stainless Steel Exchanger
R = Medium Heat w/ Stainless Steel Exchanger
T = High Heat w/ Stainless Steel Exchanger
Sensor Options
A = None
B = RA Smoke Detector
C = SA Smoke Detector
D = RA + SA Smoke Detector
E = CO
2
F = RA Smoke Detector and CO
2
G = SA Smoke Detector and CO
2
H = RA + SA Smoke Detector and CO
2
J = Condensate Overflow Switch (electro-mechanical controls only)
K = Condensate Overflow Switch and RA Smoke Detectors
L = Condensate Overflow Switch and RA and SA Smoke Detectors
Indoor Fan Options
1 = Standard Static Option
2 = Medium Static Option
3 = High Static Option
C = High Static Option with High Efficiency Motor (Size 16 Only)
Refrig. Systems Options
A = Standard One Stage Cooling Models
B = Standard One Stage Cooling Models with Humidi-MiZer
®
(size 07 only)
D = Two Stage Cooling Models
E = Two Stage Cooling Models with Al/Cu Condenser Coils
and Humidi-MiZer
®
M = Single Circuit, Two Stage Cooling Models
(08, 09, 12 unit sizes) (Humidi-MiZer not available)
Coil Options – RTPF (Outdoor – Indoor – Hail Guard)
A = Al/Cu – Al/Cu
B = Precoat Al/Cu – Al/Cu
C = E-coat Al/Cu – Al/Cu
D = E-coat Al/Cu – E-coat Al/Cu
E = Cu/Cu – Al/Cu
F = Cu/Cu – Cu/Cu
M = Al/Cu – Al/Cu – Louvered Hail Guard
N = Precoat Al/Cu – Al/Cu – Louvered Hail Guard
P = E-coat Al/Cu – Al/Cu – Louvered Hail Guard
Q = E-coat Al/Cu – E-coat Al/Cu – Louvered Hail Guard
R = Cu/Cu – Al/Cu – Louvered Hail Guard
S = Cu/Cu – Cu/Cu – Louvered Hail Guard
Coil Options – Novation
®
(Outdoor – Indoor – Hail Guard)
G = Al/Al – Al/Cu
H = Al/Al – Cu/Cu
J = Al/Al – E-coat Al/Cu
K = E-coat Al/Al – Al/Cu
L = E-coat Al/Al – E-coatAl/Cu
T = Al/Al – Al/Cu – Louvered Hail Guard
U = Al/Al – Cu/Cu – Louvered Hail Guard
V = Al/Al – E-coat Al/Cu – Louvered Hail Guard
W = E-coat Al/Al – Al/Cu – Louvered Hail Guard
X = E-coat Al/Al – E-coat Al/Cu – Louvered Hail Guard
Voltage
1 = 575/3/60 3 = 208-230/1/60 **
5 = 208-230/3 6 = 460/3/60
Design Revision
- = Factory Design Revision
Base Unit Controls
0 = Electro-mechanical Controls can be used with W7212
EconoMi$er
®
IV (Non-Fault Detection and Diagnostic)
1 = PremierLink™ Controller*
2 = RTU Open Multi-Protocol Controller
6 = Electro-mechanical w/ 2-Speed Fan and W7220
Economizer Controller Controls. Can be used with
W7220 EconoMi$er X (w/ Fault Detection and Diagnostic)
Intake / Exhaust Options
A = None
B = Temperature Economizer w/ Barometric Relief
F = Enthalpy Economizer w/ Barometric Relief
K = 2-Position Damper
U = Temperature Ultra Low Leak Economizer
w/ Barometric Relief
W = Enthalpy Ultra Low Leak Economizer
w/ Barometric Relief
Service Options
0 = None
1 = Unpowered Convenience Outlet
2 = Powered Convenience Outlet
3 = Hinged Panels
4 = Hinged Panels and
Unpowered Convenience Outlet
5 = Hinged Panels and
Powered Convenience Outlet
Packaging Compliance
0 = Standard
1 = LTL
Electrical Options**
A = None (Non USA models -
No SAV included)
C = Non-Fused Disconnect
D = Thru-The-Base Connections
F = Non-Fused Disconnect and
Thru-The-Base Connections
G = 2-Speed Indoor Fan (VFD) Controller
(Standard USA models - SAV included)
J = 2-Speed Fan Controller (VFD)
and Non-Fused Disconnect
K = 2-Speed Fan Controller (VFD)
and Thru-The-Base Connections
M = 2-Speed Fan Controller (VFD)
with Non-Fused Disconnect and
Thru-The-Base Connections
Example:
Position:
48TCDD08A1A5-0A0A0
123456789
10
11 12 13 14 15 16 17 18
* PremierLink controller cannot be used with Staged Air Volume (SAV™)
2-speed indoor fan motor.
**To meet new DOE mandatory efficiency requirements for U.S. installations,
2 Speed Motor (SAV) system is required. 48TC*M models for installation
in the U.S. meet DOE efficiency standard but 2 Speed (SAV) is not required
or available.
