Carson zPix 300 - Product Specification

Product specification
Connection type
USB 2.0 / 3.0
Effective*
magnification
21" monitor - 86x - 457x
Effective viewing area
4.96mm x 3.72mm
0.93mm x 0.70mm (5.3x zoom)
(without zoom)
Illumination
Optics
Sensor
Sensor resolution
Size
Weight
Four LED array
5.3x zoom lens system
CMOS
85.5 x 80 x 130.4mmmm mm
220 grams
8
1600 x 1200 pixels (UXGA)
*Please note that the effective magnification is a combination
of the optical system and a high powered digital zoom.
