1 22
PCB REF DESCRIPTION PART #
R254 Resistor 1/4W, ±5%, 2.2K . . . . . . . . . . . . . . . .50-22035
R255 Resistor 1/4W, ±5%, 2.2K . . . . . . . . . . . . . . . .50-22035
R256 Resistor 1/4W, ±5%, 4.7K . . . . . . . . . . . . . . . .50-47035
R257 Resistor 1/4W, ±5%, 33K . . . . . . . . . . . . . . . . .50-33045
R258 Resistor 1/4W, ±5%, 220Ω . . . . . . . . . . . . . . . .50-22025
R259 Resistor 1/4W, ±5%, 100K . . . . . . . . . . . . . . . .50-10055
R260 Resistor 1/4W, ±5%, 2.2K . . . . . . . . . . . . . . . .50-22035
R261 Resistor 1/4W, ±5%, 4.7K . . . . . . . . . . . . . . . .50-47035
R262 Resistor 1/4W, ±5%, 2.2K . . . . . . . . . . . . . . . .50-22035
R263 Resistor 1/4W, ±5%, 10K . . . . . . . . . . . . . . . . .50-10045
R264 Resistor 1/4W, ±5%, 4.7K . . . . . . . . . . . . . . . .50-47035
R265 Resistor 1/4W, ±5%, 2.2K . . . . . . . . . . . . . . . .50-22035
R266 Resistor 1/4W, ±5%, 470Ω . . . . . . . . . . . . . . . .50-47025
R267 Resistor 1/4W, ±5%, 470Ω . . . . . . . . . . . . . . . .50-47025
R268 Resistor 1/4W, ±5%, 2.2K . . . . . . . . . . . . . . . .50-22035
R269 Resistor 1/4W, ±5%, 1K . . . . . . . . . . . . . . . . . .50-10035
R270 Resistor 1/4W, ±5%, 1K . . . . . . . . . . . . . . . . . .50-10035
R271 Resistor 1/4W, ±5%, 2.2K . . . . . . . . . . . . . . . .50-22035
R272 Resistor 1/4W, ±5%, 33K . . . . . . . . . . . . . . . . .50-33045
R273 Resistor 1/4W, ±5%, 1K . . . . . . . . . . . . . . . . . .50-10035
R274 Resistor 1/4W, ±5%, 1K . . . . . . . . . . . . . . . . . .50-10035
R275 Resistor, 5W,±10%, 5KΩ, Wire Wound . . . . . .55-50030
R276 Resistor, 5W,±10%, 5KΩ, Wire Wound . . . . . .55-50030
R277 Resistor 1/4W, ±5%, 47K . . . . . . . . . . . . . . . . .50-47045
R278 Resistor 1/4W, ±5%, 47K . . . . . . . . . . . . . . . . .50-47045
R279 Resistor 1/4W, ±5%, 100K . . . . . . . . . . . . . . . .50-10055
R280 Resistor 1/4W, ±5%, 100K . . . . . . . . . . . . . . . .50-10055
R281 Resistor 2W, ±10%, 1.5k . . . . . . . . . . . . . . . . .54-15030
R282 Resistor 1/4W, ±5%, 22K . . . . . . . . . . . . . . . . .50-22045
R283 Resistor 1/4W, ±5%, 2.2K . . . . . . . . . . . . . . . .50-22035
R284 Resistor 1/2W, ±5%, 2.2K . . . . . . . . . . . . . . . .52-22035
R285 Resistor 1/4W, ±5%, 68K . . . . . . . . . . . . . . . . .50-68045
R286 Resistor 1/4W, ±5%, 220K . . . . . . . . . . . . . . . .50-22055
R287 Resistor 1/4W, ±5%, 470K . . . . . . . . . . . . . . . .50-47055
R288 Resistor 1/4W, ±5%, 47K . . . . . . . . . . . . . . . . .50-47045
R289 Resistor 1/4W, ±5%, 100K . . . . . . . . . . . . . . . .50-10055
R290 Resistor 1/4W, ±5%, 47K . . . . . . . . . . . . . . . . .50-47045
R291 Resistor 1/4W, ±5%, 47K . . . . . . . . . . . . . . . . .50-47045
R292 Resistor 1/4W, ±5%, 220K . . . . . . . . . . . . . . . .50-22055
R293 Resistor 1/4W, ±5%, 220K . . . . . . . . . . . . . . . .50-22055
R294 Resistor 1/4W, ±5%, 100K . . . . . . . . . . . . . . . .50-10055
R295 Resistor 1/4W, ±5%, 4.7K . . . . . . . . . . . . . . . .50-47035
R296 Resistor 1/4W, ±5%, 4.7K . . . . . . . . . . . . . . . .50-47035
R297 Resistor 1/4W, ±5%, 470K . . . . . . . . . . . . . . . .50-47055
R298 Resistor 1/4W, ±5%, 220Ω . . . . . . . . . . . . . . . .50-22025
R299 Resistor 1/4W, ±5%, 220Ω . . . . . . . . . . . . . . . .50-22025
S1 Switch, DIP, 8 Pole single throw . . . . . . . . . . . .25-02068
SYS GND Jumper, 22AWG, .500”x.175” . . . . . . . . . . . . . .44-15000
VR1 Regulator, Voltage, +15, 2A . . . . . . . . . . . . . . .60-78150
VR2 Regulator, Voltage, -15, 2A . . . . . . . . . . . . . . .60-79150
Z100 Zener Diode,16V ±5%, 1N4745A . . . . . . . . . . .61-47450
Z101 Not used
Z102 Not used
Z103 Not used
Z200 Zener Diode,16V ±5%, 1N4745A . . . . . . . . . . .61-47450
Z201 Not used
Z202 Not used
Z203 Not used
There are several differences between the two but of primary concern are power cord and
fuse values. Models with power cords containing the standard North American three prong
plug are for use with 120VAC where models with the European CEE-7 plugs are for 230V.
The following chart shows what fuse values to use for each model:
FUSE SELECTION
There are two versions of each F-Series amplifier. A 120 Volt AC version for those
countries supplying 120 and a 230 Volt version for others.
Fuse Selector Chart for 120 VAC Models
Model Fuse Value Size Carvin P/N
F1200 . . . .12A, 250V, Slow Blow............3AB, 1/4 x 1 1/2”...........70-22112
F600 . . . . .6A, 250V, Slow Blow ............3AG, 1/4 x 1 1/2”...........70-22060
F300 . . . . .3A, 250V, Slow Blow ............3AG, 1/4 x 1 1/2”...........70-22030
Fuse Selector Chart for 230 VAC (Export) Models
Model Fuse Value Size Carvin P/N
F1200 . . . . .6A, 250V, Slow Blow ............3AG, 1/4 x 1 1/2”...........70-22060
F600 . . . . .3A, 250V, Slow Blow ............3AG, 1/4 x 1 1/2”...........70-22030
F300 . . . .1 1/2A, 250V, Slow Blow..........3AB, 1/4 x 1 1/2”...........70-22015
Warning: Installing a wrong value fuse can damage the amplifier or create a fire hazard.
INSPECT YOUR AMPLIFIER FOR ANY DAMAGE which may have occurred during ship-
ment. If any damage is found, notify the shipping company and call CARVIN immediately.
SAVE THE CARTON & ALL PACKING MATERIALS. In the event you have to reship this
amplifier, always use the original carton and packing material. This will provide the best
possible protection during shipment. Neither CARVIN nor the shipping company are liable
for damage caused by improper packing.
SAVE YOUR INVOICE. It will be required for warranty service. Immediately check your
invoice against the items received.
SHIPMENT SHORTAGE. If items are missing, it may be that they were shipped separate-
ly. Please allow several days for the balance of your order to arrive before inquiring. If you
determine (after allowing an appropriate amount of time) you have not received all the
items you ordered, please call CARVIN.
Carvin’s USA toll free number: 800-854-2235
RECEIVING INSPECTION
