3-CONTROLSANDINSTRUMENTS

Forwardcontrols

Acceleratorlever

Thethrottleleverisplacedonrighthandsideoftheop-

eratorbesidetheFNRleverallowsthechangeofengine

RPMbycontrollingtheFIP(FuelInjectionPump)Lever.

TherangeofLeveris900–2300RPM.

PTIL15COM0402AB1

Travelcontroller(FNR)lever

Itallowsthemovementofthemachineinselecteddirec-

tiondrive.

Pressvibrationcutoffswitch(A)toONandsecondpress

toOFF .

PTIL15COM1725AB2

Bothdrumfrequencyselectorswitch

Tooperatethemachineinbothdrumhighorlowfre-

quencymode,selectthedesiredmodebyrotatingthe

switch.

PTIL15COM0061AB3
