Case IH ActiveDrive 8 User Manual

7
Controls
1. Lowering speed adjustment rear hitch.
2. Sensitivity draft control system.
3. Height limitation rear hitch.
4. Slip control value [%].
5. Remote valve configuration oil flow, timer. Pushturn logic.
6. Lift height limitation front hitch.
7. Lowering speed adjustment front hitch,
(FrontHitchManagement only).
1
2
3
4
5
6
7
3
5
1
2
4
CONTROL ELEMENTS ON C-PILLAR
1. Hydraulic main switch
Up: Remote valves active
Center: Remotes, rear hitch locked
Down: Remotes + rear hitch active
2. Heated front and rear screen
3. ISOBUS class 3 activation
4. Electronic battery isolator
5. Trailer brake test switch
